HEATERS-Heater hose installation w/o ambient temp/speed pack - 8 cyl. 7.3L diesel-F250SD/550SD

2 1/2'' WORM CLAMP; ATTACHES TURBO AIR OUTLETS FROM "Y" ADAPTOR TO CYLINDER HEAD INLET.

3 1/2 INCH CLAMP - #397257-R1 - CLAMP FOR MOUNTING THE 6C640 TURBO MANIFOLD HOSES

3 1/2" CLAMP. AIR INLET HOSE TO TURBO INLET 2 REQUIRED. (1 PER PACKAGE)

NAVISTAR #1824400-C1, FORD #F81A 8287-EA - INLET TO EXHAUST SYSTEM - ATTACHES 6K682(TURBO) TO 6K854(ADAPTOR) - PKG OF 1

V-BAND TURBO OUTLET CLAMP FROM TURBO TO 6K889

#2 IN ILLUSTRATION - RETURN HOSE.

#1 IN ILLUSTRATION. RETURN HOSE.

HOSE ASY - HEATER CORE INLET

#1 IN ILLUSTRATION - SUPPLY HOSE WITH FLUID CONTROL VALVE.

#2 IN ILLUSTRATION. SUPPLY HOSE WITHOUT FLUID CONTROL VALVE.

#1 IN ILLUSTRATION. SUPPLY HOSE WITHOUT FLUID CONTROL VALVE.

HOSE ASY - HEATER CORE SUPPLY

Снято с производства

HOSE ASY - HEATER CORE OUTLET

HOSE ASY - HEATER CORE SUPPLY

Снято с производства

ELBOW ON FRONT PASSENGER SIDE CYLINDER HEAD.

PRESS IN HEATER HOSE FITTING WITH 1/4" FITTING ON THE SIDE.

SCREWS INTO THE INTAKE MANIFOLD NEAR THE THERMOSTAT HOUSING. HAS 1 NIPPLE TO ATTACH TO THE 8A505.

THIS PART PRESSES INTO THE FRONT RIGHT MANIFOLD NEXT TO THERM. HOUSING AND HAS ONE NIPPLE FOR HEATER INLET HOSE

NIPPLE EXITING WATER PUMP. O-RING IS 1825293C1.

FLOW RESTRICTOR - HEATER HOSE

NIPPLE EXITING FRONT PASSENGER SIDE CYLINDER HEAD.

Снято с производства

"45 DEG. " - 3/8'' - 18 - 5/8'' HOSE CONNECTION

Снято с производства

CLIP - SINGLE PIPE

Снято с производства

CLIP - DUAL PIPE
